The size of the tool holder can be customized according to customer needs.
| 装圆形整体刀片的偏头车刀 | |||||
| 型号(含左右手) | 尺寸参数Dimension | 配套刀片 | |||
| Type | h=h1 | I | b | L | Matched insert |
| CRSNR/L2020 | 20 | 30 | 20 | 150 | RNMN090700 |
| CRSNR/L2525 | 25 | 30 | 25 | 170 | RNMN120400 |
| CRSNR/L3232 | 32 | 35 | 32 | 200 | RNMN150700 |
| CRSNR/L4040 | 40 | 38 | 40 | 230 | RNMN200800 |
| CRSNR/L5050 | 50 | 38 | 50 | 250 | RNMN201000 |
| 装圆形整体刀片的中置车刀 | |||||
| 型号 | 尺寸参数Dimension | 配套刀片 | |||
| Type | h=h1 | I | b | L | Matched insert |
| CRDCN2020 | 20 | 30 | 20 | 150 | RCMX090700 |
| CRDCN2525 | 25 | 30 | 25 | 170 | RBMX090700 |
| CRDCN3232 | 32 | 35 | 32 | 200 | RCMX120700 |
| CRDCN4040 | 40 | 38 | 40 | 230 | RBMX120700 |
| CRDCN5050 | 50 | 38 | 50 | 250 | RCMX150700 |
| 切槽用圆弧车刀 | |||||
| 型号 | 尺寸参数Dimension | 配套刀片 | |||
| Type | h=h1 | I | b | L | Matched insert |
| CRDNN2020 | 20 | 30 | 20 | 150 | RNMN090700 |
| CRDNN2525 | 25 | 30 | 25 | 170 | RNMN120400 |
| CRDNN3232 | 32 | 35 | 32 | 200 | RNMN150700 |
| CRDNN4040 | 40 | 38 | 40 | 230 | RNMN200800 |
| CRDNN5050 | 50 | 38 | 50 | 250 | RNMN201000 |
| 装80°C型整体刀片的95°车刀 | |||||
| 型号(含左右手) | 尺寸参数Dimension | 配套刀片 | |||
| Type | h=h1 | I | b | L | Matched insert |
| CCLNR/L2020 | 20 | 30 | 20 | 150 | CNMN1204 |
| CCLNR/L2525 | 25 | 30 | 25 | 170 | CNMN1207 |
| CCLNR/L3232 | 32 | 35 | 32 | 200 | CNMN1607 |
| CCLNR/L4040 | 40 | 38 | 40 | 230 | |
| CCLNR/L5050 | 50 | 38 | 50 | 250 | |
| 装方形整体刀片的中置车刀 | |||||
| 型号 | 尺寸参数Dimension | 配套刀片 | |||
| Type | h=h1 | I | b | L | Matched insert |
| CSDNN2020 | 20 | 30 | 20 | 150 | SNMN0903 |
| CSDNN2525 | 25 | 30 | 25 | 170 | SNMN0904 |
| CSDNN3232 | 32 | 35 | 32 | 200 | SNMN1204 |
| CSDNN4040 | 40 | 38 | 40 | 230 | SNMN1207 |
| CSDNN5050 | 50 | 38 | 50 | 250 | SNMN1507 |
| 装方形整体刀片的45°车刀 | |||||
| 型号(含左右手) | 尺寸参数Dimension | 配套刀片 | |||
| Type | h=h1 | I | b | L | Matched insert |
| CSSNR/L2020 | 20 | 30 | 20 | 150 | SNMN0904 |
| CSSNR/L2525 | 25 | 30 | 25 | 170 | SNMN1204 |
| CSSNR/L3232 | 32 | 35 | 32 | 200 | SNMN1207 |
| CSSNR/L4040 | 40 | 38 | 40 | 230 | SNMN1507 |
| CSSNR/L5050 | 50 | 38 | 50 | 250 | SNMN2010 |
| 装方形整体刀片的前75°车刀 | |||||
| 型号(含左右手) | 尺寸参数Dimension | 配套刀片 | |||
| Type | h=h1 | I | b | L | Matched insert |
| CSKNR/L2020 | 20 | 30 | 20 | 150 | SNMN0904 |
| CSKNR/L2525 | 25 | 30 | 25 | 170 | SNMN1204 |
| CSKNR/L3232 | 32 | 35 | 32 | 200 | SNMN1207 |
| CSKNR/L4040 | 40 | 38 | 40 | 230 | SNMN1507 |
| CSKNR/L5050 | 50 | 38 | 50 | 250 | SNMN2010 |
| 装方形整体刀片的75°车刀 | |||||
| 型号(含左右手) | 尺寸参数Dimension | 配套刀片 | |||
| Type | h=h1 | I | b | L | Matched insert |
| CSRNR/L2020 | 20 | 30 | 20 | 150 | SNMN0904 |
| CSRNR/L2525 | 25 | 30 | 25 | 170 | SNMN1204 |
| CSRNR/L3232 | 32 | 35 | 32 | 200 | SNMN1207 |
| CSRNR/L4040 | 40 | 38 | 40 | 230 | SNMN1507 |
| CSRNR/L5050 | 50 | 38 | 50 | 250 | SNMN2010 |
| 装方形整体刀片的83°车刀 | |||||
| 型号(含左右手) | 尺寸参数Dimension | 配套刀片 | |||
| Type | h=h1 | I | b | L | Matched insert |
| CSXNR/L2020 | 20 | 30 | 20 | 150 | SNMN0904 |
| CSXNR/L2525 | 25 | 30 | 25 | 170 | SNMN1204 |
| CSXNR/L3232 | 32 | 35 | 32 | 200 | SNMN1207 |
| CSXNR/L4040 | 40 | 38 | 40 | 230 | SNMN1507 |
| CSXNR/L5050 | 50 | 38 | 50 | 250 | SNMN2010 |
| 装55°D型整体刀片的95°车刀 | |||||
| 型号(含左右手) | 尺寸参数Dimension | 配套刀片 | |||
| Type | h=h1 | I | b | L | Matched insert |
| CDLNR/L2020 | 20 | 30 | 20 | 150 | DNMN110404 |
| CDLNR/L2525 | 25 | 30 | 25 | 170 | DNMN110408 |
| CDLNR/L3232 | 32 | 35 | 32 | 200 | DNMN110412 |
| CDLNR/L4040 | 40 | 38 | 40 | 230 | DNMN110416 |
| CDLNR/L5050 | 50 | 38 | 50 | 250 | |
| 装方形整体刀片的75°内孔车刀 | |||||
| 型号(含左右手) | 尺寸参数Dimension | 配套刀片 | |||
| Type | h | I | φ | L | Matched insert |
| S25T-CSKNR/L | 23 | 42 | 25 | 200 | SNMN0903 |
| S32T-CSKNR/L | 30 | 45 | 32 | 230 | SNMN09T3 |
| S40T-CSKNR/L | 37 | 50 | 40 | 250 | SNMN0904 |
| S32U-CSKNR/L | 30 | 45 | 32 | 300 | SNMN1204 |
| S40U-CSKNR/L | 37 | 50 | 40 | 350 | SNMN1207 |
| 装菱形整体刀片的95°内孔车刀 | |||||
| 型号(含左右手) | 尺寸参数Dimension | 配套刀片 | |||
| Type | h | I | φ | L | Matched insert |
| S25T-CCLNR/L | 23 | 42 | 25 | 200 | CNMN0903 |
| S32T-CCLNR/L | 30 | 45 | 32 | 230 | CNMN1204 |
| S40T-CCLNR/L | 37 | 50 | 40 | 250 | CNMN1207 |
| S32U-CCLNR/L | 30 | 45 | 32 | 300 | |
| S40U-CCLNR/L | 37 | 50 | 40 | 350 | |
Q1.Are you factory or trading company?
Yes, we have factory. We are professional manufacturer with 20 years of production experience. Besides, we also do some trading.
Q2. ls free shipping possible?
We don’t offer free shipping service, but we will give you some discount if you buy large qty products.
Q3.Can you send products to our Forwarder in China?
Yes, if you have forwarder in China, l will glad to send products to him/her.
Q4.Do you make OEM?
Yes, we do. We have laser machine, can laser your logo and sizes on the body of milling cutter, also can print labels.
Q5.How about the delivery time?
According to the sizes and quantity, delivery time is different. Usually3~7days. We can tell you exact inventory state if you need.
